Super Enhanced Version Panoramic Padel Court In China

This 120*120*3mm columns Padel Court will gives you a particularly spectacular view. All columns, mesh frames, fixing plates, links and screw accessories are all matched to increase the size.

This new special design Padel Tennis Courts details as following:

First:

4 sets 120*120*3mm Columns, 8 sets 120*50*3mm upper and lower beams for supporting glass.

Side of the mesh fence:  Material: Hot-Dip Galvanized Q235 steel, Customizable Color, Size：1m*2m ,

Mesh diameter:4mm ,Mesh frame: 30*50*2mm , 4 sets lamp-post 100 * 50*3000mm,

Second:

     Artificial Grass

 This monofilament curled grass is designed for Padel Tennis.

 Height 12mm, Stitch Density: 46200 stitches/m² , Gauge: 3/16inch ,

Yarn Material: 100% PE monofilament Anti-UV Curly fiber, Yarn (Dtex): 8600dtex, Primary Backing Cloth:Fleeced backing with PET yarn reinforced + PP Anti-UV backing.

     Backing Coating:  Polyurerthane (PU) .

Thirdly

Tempered Glass: 12mm Thickness*18 pieces

Complies with European Standard EN 12150-1

Heat-resistant function. It is 5 times heat resistant than float glass and can withstand sudden temperature differences of up to 300 degrees. This makes it safer in the event of a fire.Super high strength. The strength of tempered glass is 3-5 times that of ordinary annealed float glass, so it is very safe to use tempered glass for tennis courts. Excellent edging process and drilling process. Excellent edging and drilling not only bring beautiful appearance, but also further enhance the strength of tempered glass.

Fourth

8 Sets LED Lights, each Set power is 200 W.IP 65 Waterproof .The light column is embedded inside the fence.

Height of the light column is 6000 mm, illumination reaches 300 Lux.

Fifth

All accessories and screws are made of 304 stainless steel, it can not rust for life, It is strong and does not deform, the crafts has a beautiful appearance. cutting, drilling and processing of all our accessories are done on CNC intelligent digital machines. According to technical drawing standards. There is no error in the size of the accessories. Customers can install our padel courts more easily, conveniently and accurately
